Dicing Tape ProFilm DX112A

Wafer Dicing Tape

A protective surface film, ProFilm™ DX112A helps ensure consistent, precise and repeatable wafer production yields through the use of superior coating technology. ProFilm™ DX112A offers Total Thickness Variation (TTV) control, expandable base film and a special low-extractable release liner to significantly reduce silicon residue.

  • Specially formulated PVC film for unparalleled protection
  • Coated with stable bond pressure sensitive adhesive
  • Features expandable base film
  • Results in consistent release of sawn die
  • Film is transparent and untinted to help human and electronic defect recognition

Construction
ProFilm™ DX112A is constructed in three layers:

  • Polyvinyl Chloride Base Film (4.0Mils)
  • Pressure Sensitive Adhesive (0.5Mils)
  • Release Film (0.92Mils)

Configurations
ProFilm™ DX112A is available in a variety of configurations. Standard widths include 200mm, 230mm, 250mm, 275mm, 300mm, 330mm and 400mm. Rolls are provided in splice-free lengths of 100m on a 3” I.D. plastic core. Both custom widths and lengths may be available by special request. ProFilm™ DX112A rolls are polybag wrapped and individually boxed.

Shelf Life and Storage
ProFilm™ DX112A should be stored in a climate controlled environment where conditions do not exceed 25°C (75°F). If stored as recommended, the product will yield a shelf life of 6 months from the date of manufacture found on the core label.

ProFilm™ DX112A Material Properties
The values presented for this product are typical laboratory data and may be changed without notice.

Property Typical Value Test Method / Standard
Adhesive Strength 1 1000g before UV
30g after UV
ASM D 1000
Tensile Strength 19.3 N/mm1 MD
22.0 N/mm1 MD
ASTM D 882
Elongation >175% MD
>350% TD
ASTM D 882
Thickness w/o Release Liner 112.5μ (4.5 mils) ASTM D 1005
Temperature Resistance >5 min. @ 40-45°C
Download PDF spec sheet of this product here
