Dicing Tape ProFilm DU0310J

Wafer Dicing Tape

ProFilm™ DU310J dicing tape has a protective surface film designed to assure consistent, precise and repeatable wafer production yields. Constructed with superior ultraviolet adhesive coating technology, ProFilm™ DU310J tape features Total Thickness Variation (TTV) control, expandable base film, and a special low-extractable release liner to significantly reduce silicon residue.

Dicing Tape ProFilm DU0310J Features:

  • Specially formulated polyolefin film for unparalleled protection
  • Coated with stable UV curable pressure-sensitive adhesive
  • Features expandable chloride-free base film
  • Easy die removal post UV light exposure
  • Film minimizes or eliminates die rocking and other picking defects
  • Film is transparent and un-tinted to help human and electronic vision die defect recognition

ProFilm™ DU0310J Dicing Tape is constructed in three layers:

  • Polyolefin Base Film (11.2Mils)
  • UV Sensitive Adhesive (1.0Mils)
  • Release Film (0.92Mils)

Dicing Tape ProFilm™ DU310J is available in a variety of configurations. Standard widths include 200mm, 230mm, 250mm, 275mm, 300mm and 400mm. Rolls are provided in splice-free lengths of 100m on a 3” I.D. plastic core. Both custom widths and lengths may be available by special request. Dicing Tape ProFilm™ DU310J rolls are polybag wrapped and individually boxed.

Shelf Life and Storage
ProFilm™ DU310J dicing tape should be stored in a climate controlled environment where conditions do not exceed 27°C +/- 10° and 30% RH +/- 20%. This product is sensitive to UV light, so store away from heat and direct sunlight. If stored as recommended, the product will yield a shelf life of 12 months from the date of manufacture found on the core label.

Dicing Tape ProFilm DU310J Material Properties
The values presented for this product are typical laboratory data and may be changed without notice.

Download PDF spec sheet of this product here
